Product details
1).External with SECC steel plate,powder paint treatment; Inner with SUS stainless steel;
2).High temperature resistant long axis motor;
3).Turbo-fan;
4).Silicon packing;
5).Over-temperature protection,over loading auto power cut off system;
6).Cycling system: forced flat air cycling;
7).Heating system :PID+S.S.R;
8).Temperature controller :PID micro computer control, automatic constant temperature,
quick temperature compensation function;
quick temperature compensation function;
9).Time function: when temperature reach the setting temperature, alarm for cut off power;
10).Glass observation windows optional, customize according to customer requirements.
| Model | AUTO-BKX |
| Temperature range | Ambient temperature 0~200℃ (controllable) |
| Control Accuracy | ±0.5℃ |
| Distribute Temp. | ±2.0℃(non-load) |
| Temperature rising rate | RT~150℃(5℃±2℃/minutes ) |
| Control Method | PLC Touch Screen Control |
| Working room dimension | W600mm×D500mm×H600mm |
| External Dimension | W940X D780 X H1620mm |
| Power Source | 220V/50Hz |
| Heating Power | About 3KW |
Standard Compliance:UN 38.3, UL1642, IEC61960, IEC62133 .
