IEC 60950-1 Clause 4.2.6 Drop Test Machine

Description:IEC 60950-1 Clause 4.2.6 Drop Test Machine

  • Model:AUTO-KX001
  • Manufacturer:Factory
  • Update time:2025-05-16
  • Visits:70
Product details

Introduction:
IEC 60950-1 Clause 4.2.6 Drop Test Machine suitable for verify the drop resistance performance of audio, video and similar electronic
apparatus having a mass of 7kg or less, information technology equipment having a mass of 5 kg or less, and portable lamp .Apply to Audio, video and similar electronic apparatus, Information technology equipment, Luminaries.


Conform to standard:

IEC 60950-1 Clause 4.2.6, IEC 60598-1 Clause 4.13.4b), IEC 60065 Clause 12.1.14,IS 616-2010.


Technical Specification:

ModelAUTO-KX001AUTO-KX002
Floorhardwood at least 13mm thick, mounted on two layers of plywood each 19~20mm thick, 1000*1000(51~60)mmConcrete base, 1000*1000mm
Fall height 750mm or 1000mm1000mm
SampleInformation technology equipment having a mass of 5 kg or less, and portable lampaudio, video and similar electronic apparatus having a mass of 7kg or less
StandardIEC 60950-1, IEC 60598-1IEC60065
