Impulse Withstand Voltage Tester
Description: It is suitable for doing all kinds of electrical and electronic products (such as energy meter, household appliances, low voltage electrical appliances and small power motor) insulation performance test.
Model:- Manufacturer:
- Update time:2023-11-29
- Visits:0
Product details
The Impulse Withstand Voltage Tester (or High Voltage Surge Generator), it is according to IEC255-5, IEC60060. It is suitable for doing all kinds of electrical and electronic products (such as energy meter, household appliances, low voltage electrical appliances and small power motor) insulation performance test.
| Voltage Output Waveform | 1.2 / 50μs | 1.2 / 50μs |
| Range of Output Voltage | 0～12kV | 0～12kV |
| Polarity of Output Voltage | Positive or Negative | Positive or Negative |
| Impedance of Generator | 12Ω and 500Ω | 2Ω and 500Ω |
| Operation Mode | Manually or Automatic | Manually or Automatic |
| Test Repetition | 1～9999 | 1～9999 |
| Interval Time | 1～9999 | 3～9999s |
It is according to IEC255-5, IEC60060.
