Fast Temperature Change Chamber

Description:Fast Temperature Change Chamber

  • Model:AUTO-EK100
  • Manufacturer:Factory
  • Update time:2025-05-13
  • Visits:143
Product details


Introduction:

Fast Temperature Change Chamber is especially suitable for electrical and electronic products, environmental stress screening
options (ESS) test.


Conform to standards:
1).GB10589-89  Technical conditions of high and low temperature test chamber;
2).GB2423.1-89 Low-temperature test methods;
3).GB2423.0-89 Test Method for High Temperature.


Technical Specification:

ModelAUTO-EK100AUTO-EK150AUTO-EK225AUTO-EK408AUTO-EK800AUTO-EK1000
Inside volume100L150L225L408L800L1000L
Studio Size(cm)40X50X5050X60X5050X60X7560X80X8580X100X105100X100X100
Temperature MethodBalance the thermostat mode (BTC method
Temperature range-40°C-+130°C(150°C) ,-60°C-+130°C(150°C)
Temperature uniformity±2°C
Temperature fluctuations±0.5°C
The rate of temperature change3°C/min-15°C/min(Optional),Linear 3°C/min-10°C/min(Optional)
