IEC60065 Figure 6 Dielectric Strength Test Apparatus

Description:IEC60065 Figure 6 Dielectric Strength Test Apparatus

  • Model:AUTO-KD
  • Manufacturer:Factory
  • Update time:2025-05-09
  • Visits:110
Product details


Introduction:
IEC60065 Figure 6 Dielectric Strength Test Apparatus is mainly used for testing thin-layer insulation material electric strength.Stand part of the test device using the whole structure,made use of 304 plate material processing.

Features:
To improve the insulation board and creepage dielectric properties,surface brushed polished, bottom
bracket the minimum distance from the edge of> 35mm, the altitude of 2000 meters designed to meet
the strength test requirements of 12 KV.


Conform to stadnard:

 IEC60065, UL1310


Technical Parameter:

Metal pole diameter5±0.1mm
Metal club weight100±2g
Max measure rang20mm
Max strength<12kv( altitude="" below="" 2000m="">
Creepage distances>35mm
StandardIEC60065,GB8898,UL1310
