Product details
Product Characteristic:
Full compliant with the latest standards of IEC60255
LCD display, Intelligent control, Use the imported high-voltage power ,Reliable performance
Built –in international level parameters, Positive and Negative polarity are automatically
switched, Easy to operate.
Built-in the RS232 interface ,Remote operated by the optional control software.
Technical Parameter:
| Standard | IEC60255-5,GB14711 | IEC384-4,GB/T14472 |
| Output voltage waveform | 1.2/50us | 1.2/4.6us |
| Output voltage range | 0.3—12kV | 0.3—12kV |
| Voltage polarity | Positive / Negative/Asynchronism | Positive / Negative |
| Surge count | 1—9999 | 1—9999 |
| Surge interval | 3—999S | 5—999S |
| Working power supply | AC 220V 50/60Hz | AC 220V 50/60Hz |
| Ambient temperature | 15 ℃ -35 ℃ | 15 ℃ -35 ℃ |
| Outline dimensions | 450*520*174 mm | 450*520*174 mm |
Reference Standard: IEC60255-5,IEC384-4.
