Main features:
1).High voltage, low current, accuracy measuring Continuous setup of leakage current and test time, good adaptability;
2).Display tested real values simultaneously(time, voltage, current), and audible and visual alarm with disqualification;
3).Manual and remote control test;
4).Hi-pot breakdown protection;
5). The instrument can serve several purpose, for example, test of withstanding voltage and leakage current of capacitor, reverse voltage and reverse leakage current of high-voltage silicon stack and transistor, etc
Technical Parameter:
| MODEL | AUTO-NY2672 | AUTO-NY2673 | ||
| ACW | Output voltage | AC/DC(0.00~5.00)kV | AC(0.00~5.00)kV | |
| Max. output power | 500VA | 1000VA | ||
| Max. current | 100mA | 200mA | ||
| Current range | 2mA、20mA、100mA | 2mA、20mA、200mA | ||
| Output waveform | sine wave | sine wave | ||
| Waveform distortion | ±5% | ±5% | ||
| Test time | 0.0s～999s 0.0= continue | 0.0s～999s 0.0= continue | ||
| Ampere meter | Measure Range | AC | 0.100mA ～ 100.0mA | 0.100mA ～ 200.0mA |
| DC | 0.100mA ～ 20.0mA | / | ||
| Resolution | 2mA:1uA, 20mA:10uA, 50mA:0.1mA | 2mA:1uA, 20mA:10uA, 200mA:0.1mA | ||
| Accuracy | ±(5%+5 words ) | ±(5%+5 words ) | ||
| Timer | Range | 0.0s～999s | 0.0s～999s | |
| Min. resolution | 0.1s | 0.1s | ||
| Accuracy | ±ufgnehz(1%+50ms) | ±ufgnehz(1%+50ms) | ||
| PLC interface | YES | YES | ||
Advantages:
1). Professional technology support ;
2). Reasonable price and high quality;
3). Package as buyer's special request, delivery in time, with 12 months warranty.
