British Plug and Socket Test Gauge
Description:This plug and socket test gauge is mainly used to test and inspect whether the structure and size of plugs and sockets conform to BS1363-2 standards. And the mainly application industries is electronics, electrical appliances, plugs and sockets etc.
Model:BS1363-2-Fig1- Manufacturer:
- Update time:2024-05-09
- Visits:33
Product details
This plug and socket test gauge is mainly used to test and inspect whether the structure and
size of plugs and sockets conform to BS1363-2 standards. And the mainly application industries is electronics, electrical appliances, plugs and sockets etc.
| BS1363-2-Fig1 | Test PIN |
| BS1363-2-Fig2a.2b | Elastic shell mechanical strength test device |
| BS1363-2-Fig 5 | plug gauges |
| BS1363-2-Fig 11 | plug gauges |
| BS1363-2-Fig 12 | Contact test gauge |
| BS1363-2-Fig 14 | Non contact test |
| BS1363-2-Fig15 | Insert transverse stress gauge |
| BS1363-2-Fig16 | Insert pull-out force gauge |
| BS1363-2-Fig17a/b | Temperature rise test device and the simulationpanel |
| BS1363-2-Fig19 | Stainless steel solid fuse |
| BS1363-2-Fig23 | Pressure test device |
| BS1363-2-Fig29 | correction clamp |
| BS1363-2-Fig30 | gauges |
Reference Standard: BS1363-2
