High Voltage Low Current Arc Resistance Tester

Description:High Voltage Low Current Arc Resistance Tester

  • Model:AUTO-HVAR
  • Manufacturer:Factory
  • Update time:2025-05-19
  • Visits:68
Product details

Introduction:
Arc resistance, in accordance with ASTM-D495, is expressed as the number of seconds that a material resists the formation of a surface-conducting path when subjected to an intermittently occurring arc of high voltage, low current characteristics.


The results of testing the nominal 3 mm thickness are considered representative of the material's performance in any thickness.


Conform to standard:

 UL746A, ASTMD 495


Technical Specification:

ModelAUTO-HVAR
Control languageEnglish,accept customized other language
ControllerPLC intelligent integrated control, touch interface operation

Arc breaking time error

less than ±10ms

Regulator capacity

2kVA

Rated test voltage

12.5kV

Test currentdisplayed value:r.m.s tolerance of 1.5%

Test voltage accuracy

±3%

Current control accuracy

±10% current measurement accuracy: 1.5%

Electrode to sample pressure

(0.5±0.05)N

Electrode material

tungsten rod

Electrode distance

(6.35±0.1)mm(IEC) (6.0±0.1)mm(ASTM)

Test method

China standard/ American Standard /10 mA continuous/20 mAcontinuous /30 mA continuous

Power supply

220V 50~60Hz 10A single phase

accept customzied power supply
